CREATBOT DE PLUS - Extruders Dual/Triple Head High Precision Large Print Volume 3D printer

-HIGH PRINT TEMPRATURE UP TO 420°C
-HIGH PRECISION PRINTING
-STABILITY
-LARGE BUILD SIZE 400*300*520mm
-POWER OUTAGE RESTORE & FILAMENT DETECTION
-GLASS CERAMIC PLATFORM


CREATBOT DE PLUS 3D PRINTER has a build size of 400mm x 300mm x 520mm, giving you a huge build volume combined with exceptional print quality. Now you can make larger 3D models without compromising on the quality of your product.

CREATBOT DE 3D PRINTER has a build size of 400mm x 300mm x 300mm and has a heavy-duty steel frame. This is a commercial grade FFF printer which is user-friendly, making it perfect to use in a wide range of environments including offices, classrooms or just at home.

TEMPERATURE UP TO 420°C

CreatBot are the first to publish a 420°C ultra-high temperature nozzle to the mass market. The nozzle height can be micro adjusted and also allows to print with a variety of filaments. The fantasy blue metal cooling sink can efficiently cool down the heat-break. We also accept customized orders for single/double/triple head.HIGH PRECISION

CreatBot's exclusive research and development of CreatBot DE / DE Plus 3D Printer and Extruder feeding systems allows high-speed printing, very high accuracy that reaches to 0.05mm, it allows to extrude filament steadily and
without blockage.

Precision up to:0.05mm Speed up to: 200mm/s

STABILITY

The whole-steel body does not only ensure the stability when printing but also greatly extends the usage period. The optimization and construction of the overall structure ensures a sustainable and efficient operation. The first batch of CreatBot 3D printers have been working for 5 years and more than 8000 hours.

LARGE BUILD SIZE

We provide variety of printing sizes for you reference. The largest build volume is 5 to 20 times bigger than it of other ordinary 3D printers in noadays market.

CreatBot DE PLUS build volume: 400*300*520mm

OUTAGE RESTORE & FILAMENT DETECTION

The printer will automatically memorize the current position and save the print data, lower the working platform and withdraw filament if the power suddenly turns off.

GLASS CERAMIC PLATFORM

The printer has a micro-crystal platform so that can support high thermal efficiency, you can set the parameters to turn off the hot bed automatically after the specified number of layers.

EASY TOUCH SCREEN

The printer has a 4.3" touch screen, more easy to operate. We also provide One-Key to preheat, print, home as well as other shortcut keys.

MORE FEATURES:

SIMPLE FEEDING FRAME

The stepper is separated with the Hot-End, so that the Hot-End is even lighter, smaller and will has less inertia of movement, also greater space utilization.

FILAMENT FEEDER

Geared motor can reduce speed intelligently and support super torque so that it can feed filament in high precision without slipping and delay when withdrawing the filament.

TRIPLE EXTRUDERS

Support three color printing, support printing sort of material.

• Notice: The customs fee of your country may apply. The buyer is
  responsible for all import taxes, duties, fees, and tariffs.


• Lead Time (Processing/Shipping Handling Time):
  8- 12 Business Days.


• All pictures shown are for illustration purposes only.
  Actual product may vary due to product enhancement.

• Product Condition
  Item Condition	New
  Manufacturer Warranty	12 Months
  Printing Specifications
  Print size ( X Y Z )	DE: 400*300*300mm / DE Plus : 400*300*520mm
  Print Speed	30 to 200 mm/sec
  Layer Resolution	30 to 100 microns
  Print Precision (Layer Thickness)	0.04-0.3mm
  Filament Diameter	3.00 mm (1.75 mm optional)
  Nozzle Diameter	0.4 mm (Standard) 0.3, 0.5, 0.8, 1.0 mm (Optional)
  Filament Compatibility	PLA, ABS, Carbon Fiber, PETG, etc.
  Print Plate Size	310 x 290 mm
  Print in dual color	Yes
  Print in multi color	Yes
  Mechanical Specifications
  Chassis	Power-Coated Steel, Aluminum Casting for Motion Components, POM
  Extruder Type	Geared motor (1:10 rate)
  No.of Extruders	Single/Double/Triple Extruders
  Print Plate (Build Platform)	Microcrystalline Ceramic Panel
  Software Specifications
  3D Printing Software	CreatWare
  Supported File Formats	STL, OBJ, AMF
  Operating System	Windows, Mac OS
  Temperature Specifications
  Extruder Temperature	Max 350°C (for 3.00 mm version); Max 260°C (for 1.75 mm version);
  Electrical Specifications
  Power Requirements	100V-110V or 200V-240V / 50-60Hz （Depending on your country's default voltage）
  Connectivity (Interface)	USB, SD card Supported
  Electronics Specifications
  Electronics (Motherboard)	ATmega 2560
  Shipping Specifications
  Machine weight	DE: 35 kg / DE Plus : 42 kg
  Shipping box weight	DE: 45 kg / DE Plus : 55 kg
  Machine Dimensions	DE: 590*430*560mm / DE Plus : 590*430*780mm
  Shipping box dimensions	DE: 720*560*670 mm / DE Plus:720*560*870 mm
  Shipping Location	China
  Lead Time (Processing/Handling Time)	10-12 business days
